Door handle Helix 200 - Dark bronze in the group Products / Door handles / Door handles at Beslag Design i Båstad Aktiebolag (dorrh-helix-morkbrons)

Door handle Helix 200 - Dark bronze

dorrh-helix-morkbrons

The Helix 200 door handle in dark bronze combines industrial design with elegance. The sleek combination of brown tones and subtle hints of grey has made dark bronze a popular choice for both modern and classic interior styles. The Helix 200 door handle features a knurled surface that not only enhances the design but also provides a comfortable, grip-friendly feel. The handle is self-returning, meaning it always returns to its original position after use.

Helix 200 is perfect for all interior doors, offering both aesthetic quality and high functionality. The concealed screw fitting ensures a clean installation, and the door handle matches several of Beslag Design’s other series for a cohesive style.

Helix 200 in dark bronze comes in various versions to suit both Scandinavian and European standards. Whether your door has a Scandinavian standard lock case (lock case 2014) or a European standard (cc38mm), Helix 200 offers smooth and secure installation.

A standard key escutcheon and complete installation kit are included.
The door handle and key escutcheon are suitable for doors that are 35–48 mm thick. Combine with toilet lock R for a complete look.

Specifications

Article depth:	65 mm
Article diameter:	52 mm
Article length:	150 mm
Article width:	52 mm
C/C-dimensions:	30 mm
Material:	Aluminium , Zinc
Screws included:	Complete with mounting kit

Care instructions
Assembly and Installation
Installation of door handle

1. Center square spindle in the lock.
2. Fasten the mounting plates with the included screws and caps.
3. Remove the square spindle and use it to the guiding plates located in the center of the mounting brackets.
4. Recenter the square spindle. Ensure that the spindle is placed so that the jagged surface is facing the socket set screw in the handles. Press the handles firmly until they click into place on the top of the mounting plates.
5. Tighten all four socket set screws using the included hex keys. The smaller socket set screws should be installed in the rosettes, while the larges ones should be mounted in the handles themselves.

Installation of key escutcheon

1. Fasten the mounting plates with the included screws and caps.
2. Press the outer parts until they click into place on the top of the mounting plates.
3. Tighten the socket set screws using the included hex keys.

See the full installation instructions here.
Material and Finish
Documentation
Installation manual
Product sheet
