Door handle Helix 200 Plain - Dark bronze

Door handle Helix 200 Plain - Dark bronze

helix-plain-morkbrons

The Helix 200 Plain door handle in dark bronze combines modern design with a timeless sense of elegance. With its smooth surface and sleek rounded shapes, this door handle complements both light and dark interior doors. The elegant dark bronze finish, with brown tones and grey accents, suits both modern and classic interiors.

Helix 200 Plain offers not only aesthetic beauty but also high functionality. The innovative self-returning function ensures the handle always returns to its original position after use, providing a reliable and durable solution for all interior doors.

The door handle and accompanying key escutcheon fit doors with a thickness of 35-48 mm, and the concealed screw fitting guarantees a sleek installation. Choose between a lock box in Scandinavian standard (lock box 2014) or one in European standard (cc38mm).

For a cohesive look, it is recommended to pair Helix 200 Plain with toilet lock R, and the door handle also harmonizes with many of Beslag Design’s other products, such as knobs and handles, to create a unified style throughout your home or project.

A standard key plate and a complete mounting kit are included for easy installation.

Specifications

Article depth:	65 mm
Article diameter:	52 mm
Article length:	150 mm
Article width:	52 mm
C/C-dimensions:	30 mm
Material:	Aluminium , Zinc
Screws included:	Complete with mounting kit

Care instructions
Assembly and Installation
Installation of door handle

1. Center square spindle in the lock.
2. Fasten the mounting plates with the included screws and caps.
3. Remove the square spindle and use it to the guiding plates located in the center of the mounting brackets.
4. Recenter the square spindle. Ensure that the spindle is placed so that the jagged surface is facing the socket set screw in the handles. Press the handles firmly until they click into place on the top of the mounting plates.
5. Tighten all four socket set screws using the included hex keys. The smaller socket set screws should be installed in the rosettes, while the larges ones should be mounted in the handles themselves.

Installation of key escutcheon

1. Fasten the mounting plates with the included screws and caps.
2. Press the outer parts until they click into place on the top of the mounting plates.
3. Tighten the socket set screws using the included hex keys.

See the full installation instructions here.
Material and Finish
Documentation
Installation manual
Product sheet
